Description:
CNG steel cylinders and composite cylinders are widely used for vehicles. Type 1 CNG steel cylinders are made of chrome molybdenum steel. Type 2 CNG composite cylinders are made of a mixture of fiberglass or carbon fibers. The working pressure of CNG steel cylinder for vehicle is 200bar, and the testing pressure is 250bar. Our CNG cylinder for vehicle with ISO standard may apply for the certificate and reports issued by the international third inspection origination. Steel cylinder can be packaged with bag, while glass fiber composite cylinder may be packaged with carton.
Properties:
1.CNG steel cylinders and composite cylinders have same safety performance, and there are no big differences on the use.
2.Fiber composite cylinder is 66% lighter than CNG steel cylinders. They can greatly improve fuel economy, reduce vehicle maintenance costs.
3.Users can choose the CNG cylinder for vehicle according to their actual needs.
Parameters of CNG Steel Cylinder:
|
Wide range of body size
|
OD 232mm, OD 279, OD 325, OD356, OD406 and etc.
|
|
Wide range of volume
|
20L-150L
|
|
Liner Material
|
30CrMo, 34CrMo
|
|
Composite material
|
Glass fiber
|
|
Operation pressure
|
200bar
|
|
Testing pressure
|
250bar
|
|
Standard and Certification
|
GB, ISO and etc.
|
Founded in October 2006, Chongqing Anran Gas Technology Co Ltd. is a professional manufacturer and supplier of CNG cylinder for vehicle in China. Besides natural gas cylinders, we also provide CNG compressors, CNG conversion kits, current distributors, inverters, power generation equipment and so on. Our CNG steel cylinder for vehicle with ISO standard may apply for the certificate and reports issued by the international third inspection origination.
